2500LB Integral Flanged Globe Valve, Bolted Bonnet

Design Construction:
ASME B16.34, BS 5352
Testing according to API 598
Face to face according to ASME B16.10
Flanges according to ASME B16.5
Spiral wound gasket
Integral backseat
Integral body flanges
Marking MSS SP25
Outside Screw and Yoke (OS&Y)
Loose disc stem assembly
Self aligning two piece packing gland

Ratings:
- carbon steel class 150 285 psig @ 100°F 20 bar + 38°C
- carbon steel class 300 740 psig @ 100°F 51 bar + 38°C

DN
L


H


W


P


A


B


C


T


F


n-


kg

(in)
1/2 15 264 321 180 42.9 65.1 89.0 133 30.5 6.35 4-23 16.7
3/4 20 273 321 180 50.8 73.0 95.2 140 32.0 6.35 4-23 17.0
1 25 308 321 180 60.3 82.5 107.9 159 35.0 6.35 4-26 24.3
11/4 32 352.2 373 200 72.2 101.6 130.2 184 38.5 7.92 4-29 30.8
11/2 40 387.2 406 200 82.6 114.0 146.0 203 44.5 7.92 4-32 40.5
2 50 454.2 495 300 101.6 133.0 171.4 235 51.0 7.92 8-29 45.5
